TEMPERATURE SENSORS FOR COMBUSTION ENGINES

TEMPERATURE MEASUREMENT TECHNOLOGY FOR VEHICLE DEVELOPMENT



We actively contribute to the development of trucks , buses and cars for the future of the automotive industry. TEMPCO SENSORS /RÖSSEL-Messtechnik has supplied the automotive industry with temperature sensors for several decades. We also offer measurement technology designed for hydrogen technology and e-mobility. Our products are suitable for temperature measurement on hybrid supply lines, in battery systems and on the outer casing of high-voltage components. Acid, oil and fuel-resistant thermocouples and resistance thermometers are just as important in the automotive industry.
Rely on our expert advice along the entire production chain. With a wide range of products, custom sensor design and flexible manufacturing in small and large quantities, we are the optimum partner for your requirements.

For many decades all the German car manufacturers are adviced and supplied by us with high quality products against very competive prices and reliable delivery times.




Standard metal sheathed thermocouple
(with or without connection cable)



Sheathed thermocouple with flexible sheath material Inconel600.

Thermocouple of NiCr-Ni alloy for the temperature range -200 to 1372°C.

Transition sleeve 6 x 50 (optionally 5 x 35 or 4 x 25 mm) for contacting with the connection cable.

Extension cable type K with PFA insulation acc. to DIN 43 722.

Deviation acc. to DIN EN 60 584, class 1.


Areas of application:

Exhaust temperature measurement inside exhaust pipe, catalyzer, diesel-particulate filter, turbo charger.

Surface temperature by mounting with a welding plate.

Cooling water and oil temperature by mounting with a screw joint.

Furtherapplications on reqquest.


Screw-in thermocouple



Metal Sheathed thermocouple with flexible sheath material Inconel600.

With direct screw-in thread M10x1 and variable insertion length.

Thermocouple in NiCr-Ni alloy for the temperature range -200 to 1372 °C.

Extension cable type K with PFA insulation acc. to DIN 43 722.

Deviation acc. to DIN EN 60 584, class 1.



Areas of application:

Cooling water and oil temperature.

Further applications on request.










Brake disc thermocouple
(with connection cable)



Thermocouple, mounted in mounting sleeve for attaching to brake caliper, spring-bedded.

Thermcouple in NiCr-Ni alloy for the temperature range -50 to approx. 260 °C.

Extension cable type K with PFA insulation acc. to 43 722.

Deviation acc. to DIN EN 60 584, class 1.






Thermocouple sensor flexible constuction for measurement at cooling hose ors soft underground.

Easy to mount with for example  tiewraps.


Flex thermocouple



Thermocouple in flexible spiral hose in diameter 3.0 mm and 4.5 mm.

Thermocouple in NiCr-Ni alloy for the temperature range -50 to approx. 260 ºC.

Extension cable type K with PFA insulation according to DIN 43 722.

Deviation according to DIN EN 60584, class 1

Ordering example : FLEX-TE-T-400-1K+/-0,25L-1000



Areas of application:

Temperature measurement via the inlet branch of the oil dipstick with variable length in 2 diameters.

Option of ordering supplies:

VN screw joints for the sealing at the inlet branch.

Further applications on request.


Black standard thermocouple

(with connection plug)

Our type : TE Thermocouple installed with solar measuring plate.

Thermocouple of NiCr-Ni alloy for the temperature range -200 to approx. 260 ºC.

Extension cable type K with PFA insulation according to DIN 43 722.

Deviation according to DIN EN 60 584, class 1.

Ordering example : TO-11070-SWT-K-1

Areas of application:

Temperature measurement at solar-heated surfaces in insolation systems or climate garages.



Extension cables (individual and multiple)

Our type : Adapter Extension cables with miniature plug and miniature socket for the extension of the connection cables of a thermocouple, or with connected Lemo plug or socket.

Versions with two-wire,16-wire and 32-wire cables. 16- and 32-wire versions with aluminum block for the reception of the miniature sockets.

Extension cable type K with PFA insulation according to DIN 43 722.

Deviation according to DIN EN 60 584, class 1.

Ordering example : ADAPTER 1 M TT-465-2K-0,22L

For further information please request.
